How do I set up the Trigger Module in EMGworks?
Solution
The Delsys Trigger Module can be used to send out or receive both Start and Stop pulses for synchronization with 3rd-party systems. In this scenario, we will assume the 3rd-party system(s) will be responsible for triggering the Trigno System. Thus, the sync pulse will be generated and sent to the Delsys Trigger Module’s input BNC connectors – the top right (Start) and, if applicable, top left (Stop).
If you wish to have the Delsys Trigger Module send out a sync pulse for starting and/or stopping 3rd-party system(s), simply connect from the output BNC connectors. No other selections are required in the EMGworks software, by default the Trigger Module sends out start and stop sync pulses when the ‘Start’ and ‘Stop’ buttons are pressed in EMGworks Acquisition.
- Plug the Trigger Module’s connector into the Base Station’s trigger port The red dot on the cable’s connector should be facing downwards.
- Turn the Trigger Module on with the toggle switch. Illuminated light indicates Trigger Module is on.
- Ensure all BNC connectors are secured between the Trigger Module and 3rd-party systems.
- Navigate to the General settings of your Workflow Template tasks in EMGworks Acquisition. Most commonly, users will be working with the Plot and Store template.
The Delsys Trigger Module can be used to send out or receive both Start and Stop pulses for synchronization with 3rd-party systems. In this scenario, we will assume the 3rd-party system(s) will be responsible for triggering the Trigno System. Thus, the sync pulse will be generated and sent to the Delsys Trigger Module’s input BNC connectors – the top right (Start) and, if applicable, top left (Stop).
If you wish to have the Delsys Trigger Module send out a sync pulse for starting and/or stopping 3rd-party system(s), simply connect from the output BNC connectors. No other selections are required in the EMGworks software, by default the Trigger Module sends out start and stop sync pulses when the ‘Start’ and ‘Stop’ buttons are pressed in EMGworks Acquisition.
- Plug the Trigger Module’s connector into the Base Station’s trigger port The red dot on the cable’s connector should be facing downwards.
- Turn the Trigger Module on with the toggle switch. Illuminated light indicates Trigger Module is on.
- Ensure all BNC connectors are secured between the Trigger Module and 3rd-party systems.
- Navigate to the General settings of your Workflow Template tasks in EMGworks Acquisition. Most commonly, users will be working with the Plot and Store template.
- Depending on your desired trigger setup, choose whether you’ll be using a Start trigger, Stop trigger, or both.
- Click Start Test › Name test run › Okay › Start on recording screen.
- At this point, the system is armed but no data will appear. As soon as the 3rd-party trigger pulse is delivered to the Start input connector, data will stream.
- The recording will end when receiving a Stop trigger (if this option was selected). However, users can still allow the run to end based on the set Run Time or by simply hitting ‘Stop’ on the recording screen.
The Delsys Trigger Module does offer various edge settings and pulse width settings for handling incoming or outgoing synchronization pulses. For complete technical details please refer to the User’s Manual.
